BR473

View installers & retailers Find another part

Brake Disc

Part number: BR473
Active

Specifications

  • Brake Disc TypeVented
  • Coated
  • Weight4.4
  • Outer Diameter240
  • Brake Disc Thickness21
  • Min. thickness19
  • Height45
  • Centering Diameter126
  • Num. of holes4
  • Quantity1
Download full size diagram for printing
